Table of contents Mounting interfaces
Mounting interfaces
• standards for hydraulic valve interfaces
INFORMATION
There is considerable confusion over standards as applicable to the valve interfaces depicted below.
NG3-Mini NG6
Wandfluh standard ISO 4401-03
∗ Note:
Wandfluh delivers his products
without center bore and center
pin.
NG4-Mini
Wandfluh standard
NG10
ISO 4401-05
∗
NG4
ISO 4401-02
∗
∗ Important:
T is not drilled in subplates NG3, NG4 and NG10, but T is
0
0
included in most of sandwich- and flange valves.
Wandfluh AG Tel. +41 33 672 72 72 E-mail: [email protected] Illustrations not obligatory Data sheet no.
Postfach Fax +41 33 672 72 12 Internet: www.wandfluh.com Data subject to change 1.0-30E 1/1
CH-3714 Frutigen Edition 03 24
