Solenoid operated spool valve
Solenoid operated spool valve Solenoid operated spool valve

GENERAL SPECIFICATIONS ACCESSORIES DIMENSIONS / SINGLE MONITORING
Weight 1,30 kg single flange Mating connector (plug female) 4/3-way spool valve (spring centred) 4/2-way spool valve (spring reset) operation A-side
2,60 kg double flange straight, screw terminal Article no. 219.2978 MD= 10.5Nm(8.8)
13.5Nm(10.5)
Sensor Specifications: 90°, screw terminal Article no. 219.3003 A S2 S1 B A S1
Operating voltage 10…36 VDC
Signal current max. 200 mA 64 0.5 70 100.75

IP 68 29.5
According to the connection type, the
Protection class 379.2 6.5
protection class of the valve can be SURFACE TREATMENT
lower, see data sheet 1.2-76 ◆ The valve body is painted with a two component paint 10.5
Dimensions M12 x 1 ◆ All the other parts are zinc-nickel coated 35 72 92.6 36.6 14.1
250.3
Ambient temperature -25…+70 °C

Fastening torque 15 Nm 4/2-way spool valve (impulse) 4/2-way spool valve (spring reset) operation B-side
Peak pressure 500 bar A S1 B S2 B
Note! Other specifications, see data sheet 1.2-76

343.2 250.3
ELECTRICAL CONNECTION

Type: PNP, NO (Normally open) or NC Type: NPN, NO (Normally open)
(Normally closed)
Designation: P1 Designation: P2
Article no.: 205.5028 Article no.: 205.5027 DIMENSIONS / DOUBLE MONITORING
Device receptacle M12, 4 pole male Device receptacle M12, 4 pole male 4/2-way spool valve (spring reset) operation A-side
1 = Supply voltage + 1 = Supply voltage +
2 1 2 1 A S2 S1
2 = Signal NC 2 = Reserved for extentions
3 4 3 = Supply voltage 0 VDC 3 4 3 = Supply voltage 0 VDC
1 4 = Signal NO 4 = Signal
2 1
4 Plus switched 4 Minus switched
3 3
Mating connector M12, 4 pole female Mating connector M12, 4 pole female 286.3
(not included in delivery) (not included in delivery)
4/2-way spool valve (impulse) 4/2-way spool valve (spring reset) operation B-side

A S2 S1 B S2 S1 B
Signal characteristics
Signal of the Signal of the sensor
actuator
NO NC
Normally open Normally closed 379.2 286.3
A B S1 S2 S1 S2
0* 0* 0* 0* 1* 1*
0 1 0 1 1 0
1 0 1 0 0 1
*Middle position 4/3-way

Wandfluh AG Postfach CH-3714 Frutigen
Tel. +41 33 672 72 72 Fax +41 33 672 72 12 [email protected]

www.wandfluh.com Illustrations are not binding Data subject to change 2/3 Edition: 22 12 1.2-78 E www.wandfluh.com Illustrations are not binding Data subject to change 3/3 Edition: 22 12 1.2-78 E
