Proportional spool valve
Proportional spool valve

Proportional spool valve stainless
NG6
Flange construction ISO 4401-03
◆ Q = 30 l/min
max
◆ 3 volume flow levels x II 2 G Ex db IIC T6, T4
◆ Q N max = 20 l/min x II 2 D Ex tb III C T80 °C, T130 °C
◆ p = 350 bar x I M2 Ex db I Mb
max
Class I Division 1
Class I Zone 1

DESCRIPTION APPLICATION
Direct operated proportional spool valve with 4 connections in These valves are suitable for applications in explosion-hazard areas,
5-chamber system. Precise spool fit, low leakage, long service life open cast and also in mines. The stainless execution is especially
time. Proportional to the solenoid current, the spool stroke, the spool suitable for the use in wet and salty environment. Proportional spool
opening and the valve volume flow increase. The pressure tight en- valves are perfectly suitable for demanding tasks due to the high re-
capsulated Ex-protection solenoid coil prevents an explosion on the solution, large volume flow and low hysteresis. The applications are
inside penetrating to the outside as well as an ignitable surface tem- in the industrial as well as in the mobile hydraulics for the smooth

perature. control of hydraulic actuations.

CERTIFICATES ACTUATION

Surface Mining Standard M248 Actuation Proportional solenoid, wet pin push
-25 °C Electronic type, pressure tight
to… Execution MKY45 / 18x60 (data sheet 1.1-183)
ATEX x x x x MKU45 / 18x60 (data sheet 1.1-184)
IECEx x x x x Connection Cable gland for cable Ø 6,5…14 mm
CCC x x x x Attention! The UL execution is always supplied without cable
EAC x x x x gland
Australia x x x
MA x x x
UL / CSA x x
The certificates can be found on www.wandfluh.com

SYMBOL
Symmetrical control
ACB-S AC1-S CB2-S

A B A B A B
a 0 b a b
a b a b a b
P T P T P T

Meter-in control
ADB-V AD1-V DB2-V

A B A B A B
a b a b
a b a b a b
P T P T P T

www.wandfluh.com Illustrations are not binding Data subject to change 1/6 Edition: 21 18 1.10-88S E
