Overview
Poppet valve cartridge
Solenoid poppet valves Poppet valve cartridges

Solenoid poppet valve cartridge
NG3-Mini NG4-Mini NG6 ISO NG10 ISO • normally closed
• Q max = 6 l/min NG3
• p = 350 bar
Types max

Z.32060b-S1827 Z.320100b-S1827
DESCRIPTION FUNCTION APPLICATION
The 2/2-way seating valve in slip-in cartridge The seating valve piston is held against the Wandfluh poppet valves can be used anywhe-

form is the central control element of virtually spring by the pressure-tight control solenoid. re absolutely leak tight closing functions are
all directly-controlled seating valves in nominal Because the seat-piston design has equal sur- important. Completely sealed loading, grip-
size 3-Mini. The seating valve cartridge, the face areas on both sides and since the seat/ ping and clamping operations are all important
Z.32061a-S2039 spring, one O-ring and a washer are supplied piston construction is balanced in terms of functions which Wandfluh poppet valves can
separately. A solenoid (VDE standard 0580) pressure, no undesirable closing and opening perform. Cartridge typ poppet valves can be
is an optional addition. forces are generated. As a result, oil can flow neatly accommodated in valve blocks. Cavity

Important: at the time the valve is taken into in both directions through the seating valve. tools are available for hire or sale for machi-
service, the valve must be vented under pres- The seat/piston guide is sealed with an O-ring. ning aluminium or steel.
sure (max. 2 revolutions of screw E). The seat with a metallic seal closes off the See data sheet register no. 2.13.
Z.32061a-S1062 Z.32101a-S1062 valve so that there is no leakage oil.

TYPE CODE

Poppet valve cartridge 2 2 03 #
Poppet valve cartridge with solenoid 2 2 03 - #
Z.32060b-S1062 Z.32100b-S1062
Medium-solenoid M
Super-solenoid S

2-way (Connections)
Z.3406-S1011 Z.3410-S1011 2 Position
Nominal size 3

Nominal voltage U 12 VDC G12 110 VAC R110
N
24 VDC G24 115 VAC R115
230 VAC R230
Design-Index (Subject to change)

GENERAL SPECIFICATIONS ELECTRICAL CONTROL
Description 2/2-way poppet valve Construction Solenoid, wet pin push type, pressure tight
Nominal size NG3 Standard-nominal flow U = 12 VDC
N
Construction Direct operated poppet valve U N = 24 VDC
Operations Solenoid U N = 110 VAC∗
Mounting cartridge form U N = 115 VAC∗
4 solenoid fixing screws M3 U N = 230 VAC∗
Ambient temperature -20…+50 °C A C = 50 to 60 Hz
Mounting position any ∗ Rectifier integrated in the plug
Fastening torque M = 1,2 Nm (quality 8.8) Other nominal voltages and nominal
D
Weight: 2203 m = 0,015 kg performances on request
. 2203- . . m = 0,225 kg Voltage tolerance ±10% of nominal voltage
Volume flow direction any Protection class IP 65 to EN 60 529
Relative duty factor 100% DF (see data sheet 1.1-430)
Switching cycles 15 000/h
Operating life 10 (number of switching cycles, theoretically)
7
HYDRAULIC SPECIFICATIONS Connections/ Over device plug connection to
Fluid Mineral oil, other fluid on request ISO4400/Power supply DIN 43650,
Contamination efficiency ISO 4406:1999, class 20/18/14 (2P+E), other connections on request.
(Required filtration grade ß10…16≥75) Solenoid: – Medium SIN29V (data sheet 1.1-80)
refer to data sheet 1.0-50/2 – Super SIS29V (data sheet 1.1-85)
Viscosity range 12 mm /s…320 mm /s
2
2
Fluid temperature -20…+70 °C SYMBOLS
Working pressure Medium: p max = 125 bar 2203 . 2203- . .
Super: p max = 350 bar
Max. volume flow Q = 6 l/min, see characteristics
max
