Overview
Overview electronics
Electronics

Programming tools

Orchestra TM Project management software article no. 740.1000 contains:
Composer TM For developing software by means of intuitive «Ladder-Logic» programming. Simple definition of a
complete system from inputs and outputs to CAN messaging with minimal programming knowledge.
Presto TM Orchestra TM project definition tool for C / C ++ application programming, with the 3 party tool CodeWar-
rd
rior™ for the C-code compilation. The respectively required NXP (Freescale) Suite «CW-SUITE-STAN-
DARD: CodeWarrior® Development Suite-Standard» (contains «HCS12 (X) Edition» version 5.1 and
«Microcontrollers Edition» version 10.6) is not contained in Orchestra™.
It must be ordered directly from NXP.
Arranger TM The graphic display can be programmed with pre-prepared graphical elements simply with Drag & Drop.
The program variables can be assigned to these elements in order to make the desired inputs and out-
puts via the display.
Conductor TM Diagnostic and set-up tool. Real-time view of system inputs, outputs and variables. Conductor is part
of Orchestra , but it is also available as an autonomous software with separate license dongle.
TM
Article no. 740.1001
Additional tools
USB-to-CAN-adapter The adapter is needed for downloading software on PME modules, which do not have a USB interface.
TM
Not contained in Orchestra .
PCAN-USB from Peak-Systems or from Gridconnect.
C-Code Debugging Development tool for C-code debugging using JTAG interface.
Not contained in Orchestra . Must be ordered via P & E Microcomputer systems.
TM
