Solenoid operated spool valve
Solenoid operated spool valve

PERFORMANCE SPECIFICATIONS
Oil viscosity u = 30 mm /s
2
p = f (Q) Performance limits 100 Ω p = f (Q) Performance limits 152 Ω
p [bar] AB_/ACB ADB AB3 p [bar] AB_ / ACB AB3
350 K1181 350 K4208 ADB
300 300
250 250
200 200
150 150
100 100
50 50
0 0
0 4 8 12 16 20 Q [l/min] 0 4 8 12 16 20 Q [l/min]

Δp = f (Q) Pressure drop volume flow characteristic Q = f (p) Leakage volume flow characteristic
L
P → T
p [bar] Q [cm /min] Standard
3
50 K1182 80 K1183
40
60
30
40
20
10 20
0 0
0 4 8 12 16 20 Q [l/min] 0 50 100 150 200 250 300 350 p [bar]

Q [cm /min] Low leakage
3
Attention! If, because of the given operating conditions, during the 80
switching process volume flows occur which exceed
the power limit of the valve, these have to be limited by 60
a throttle or an orifice in connection P.
In case of a continuous flow through, the throttle or 40
orifice, depending on the system behaviour, an 20
additional heating-up of the valve is possible. This has
to be appropriately taken into account by the user. 0 0 50 100 150 200 250 300 350 p [bar]

ACCESSORIES MANUAL OVERRIDE
Fixing screws Data sheet 1.0-60 HB4,5 as standard
Threaded subplates Data sheet 2.9-10
Multi-station subplates Data sheet 2.9-50
Module type manifold blocks Data sheet 2.9-90
Technical explanations Data sheet 1.0-100 SEALING MATERIAL
Filtration Data sheet 1.0-50 NBR or FKM (Viton) as standard, choice in the type code
Relative duty factor Data sheet 1.1-430

STANDARDS SURFACE TREATMENT

Explosion protection Directive 2014 / 34 / EU (ATEX) ◆ The valve body is painted with a two component paint
Mounting interface ISO 4401-03 ◆ The armature tube, the slip-on coil and the plug screw are
Protection class EN 60 529 zinc-nickel coated
Contamination ISO 4406
efficiency

www.wandfluh.com Illustrations are not binding Data subject to change 3/4 Edition: 19 26 1.3-42 E
