Poppet valve cartridges Poppet valve cartridges
Poppet valve cartridge

CHARACTERISTICS Oil viscosity υ = 30 mm /s Solenoid poppet valve cartridge
2
p = f (Q) Performance limit at -10% • normally closed
p [bar] 1 • Q = 80 l/min NG10
350 K0128 Flow directions • p max = 350 bar
300 2 Type 1 → 2 2 → 1 max
3
M2206
3
250 S2206 1 2
200 3
150
100 DESCRIPTION FUNCTION APPLICATION
50 The 2/2-way seating valve in slip-in cartridge The seating valve piston is held against the Wandfluh poppet valves can be used anywhere
0 form is the central control element of virtually spring by the pressure-tight control solenoid. absolutely leak tight closing functions are im-
0 5 10 15 20 25 30 35 40 Q [l/min] Medium all directly-controlled seating valves in nominal Because the seat-piston design has equal portant. Completely sealed loading, gripping
∆p = f (Q) Pressure loss / flow characteristics size 10. The seating valve cartidge, the stroke surface areas on both sides and since the and clamping operations are all important
seat / piston construction is balanced in terms of
limiting piston, the spring, one O-ring and a
functions which Wandfluh poppet valves can
p [bar] washer are supplied separately. A solenoid pressure, no undesirable closing and opening perform. Cartridge typ poppet valves can be
30 K0129 (VDE standard 0580) is an optional addition. forces are generated. As a result, oil can flow in neatly accommodated in valve blocks. Cavity
25 Important: at the time the valve is taken into both directions through the seating valve. The tools are available for hire or sale for machining
20 service, the valve must be vented under pres- seat / piston guide is sealed with an O-ring. The aluminium or steel. See data sheet register
15 sure (max. 2 revolutions of screw E). seat with a metallic seal closes off the valve so no. 2.13.
that there is no leakage oil.
10
5 TYPE CODE
0
0 5 10 15 20 25 30 35 40 Q [l/min] Poppet valve cartridge 2 2 10 #
Poppet valve cartridge with solenoid 2 2 10 - #
DIMENSIONS
Medium Super Medium-solenoid M
Super-solenoid S
2-way (Connections)
2 Position

Nominal size 10
Super
Nominal voltage U N 12 VDC G12 110 VAC R110
24 VDC G24 115 VAC R115
230 VAC R230
Design-Index (Subject to change)

For detailed cavity drawing GENERAL SPECIFICATIONS ELECTRICAL CONTROL
and cavity tools see data Description 2/2-way poppet valve cartridge Construction Solenoid, wet pin push type,
sheet 2.13-1014 Nominal size NG10 pressure tight
Construction Direct operated poppet valve Standard-nominal flow U = 12 VDC, U = 24 VDC
N
N
Operations Solenoid U = 110 VAC∗, U = 115 VAC∗
N
N
Mounting cartridge form U = 230 VAC∗
N
PARTS LIST 4 solenoid fixing screws M6 AC = 50 to 60 Hz
Ambient temperature -20…+50 °C ∗ Rectifier integrated in the plug
Position Article Description Mounting position any Other nominal voltages and nominal
Fastening torque M = 8,9 Nm (quality 8.8) performances on request
D
10 500.3000 Poppet valve cartridge 2206 Medium Weight: 2210 m = 0,12 kg Voltage tolerance ±10% of nominal voltage
500.3013 Poppet valve cartridge 2206 Super . 2210- . . m = 1,98 kg Protection class IP 65 to EN 60 529
11 053.2600 Spring 1,2 x 7,2 x 15 Medium Volume flow direction any (see characteristics) Relative duty factor 100% DF (see data sheet 1.1-430)
053.2616 Spring 1,2 x7,2 x 16 Super Switching cycles 15 000/h
Operating life
7
10 (number of switching cycles, theoretically)
12 222.0041 Pin E = air bleed screw HYDRAULIC SPECIFICATIONS Connections / Power supply Overdevice plug connection to
13 212.0502 Washer (only for Super) ∗ Cartridge supplied with fastening screw M5 x 63 for steel bodies/ Fluid Mineral oil, other fluid on request ISO4400 / DIN 43650, (2P+E),
14 160.2108 O-ring ID 10,82 x 1,78 blocs. For aluminium bodies/blocs longer screws are recommended Contamination efficiency ISO 4406:1999, class 20/18/14 other connections on request
15 160.2156 O-ring ID 15,60 x 1,78 (min. 2 screw diameter). (Required filtration grade ß10…16≥75) Solenoid: – Medium SIN60V (data sheet 1.1-145)
refer to data sheet 1.0-50/2
16 160.2236 O-ring ID 23,52 x 1,78 Medium Viscosity range 12 mm /s…320 mm /s – Super SIS60V (data sheet 1.1-150)
2
2
160.2161 O-ring ID 16,00 x 1,5 Super ACCESSORIES Fluid temperature -20…+70 °C
20 260.6 . . . Medium-solenoid SIN45V Cartridge built in flange- or sandwich body: Working pressure Medium: p max = 160 bar
260.7 . . . Super-solenoid SIS45V Flange Register 1.11 Super: p max = 350 bar SYMBOLS
Sandwich Register 1.11
30 239.2033 Plug HB0 Max. volume flow Q max = 80 l/min, see characteristics 2210 . 2210- . .
40 219.2002 Plug Special tool 983.2001 to poppet valve cartridge 2206.
50 249.2001 Socket head cap screw M5 x 63
Technical explanation see data sheet 1.0-100
