Poppet valve cartridges Poppet valve
Poppet valve cartridge

CHARACTERISTICS Oil viscosity υ = 30 mm /s Solenoid operated poppet valve cartridge
2
p = f (Q) Performance limit at -10% ◆ solenoid operated M20 x 1,5
p [bar] ◆ direct operated
350 K0158 1 ◆ normally closed
300 Flow direction ◆ 2/2-way
250 2 Type 1 → 2 2 → 1 ◆ Q = 15 l/min
200 M2210 3 4 p = 250 bar
max
S2210
1
2
150 ◆ max
100 3
50 4
0
0 10 20 30 40 50 60 70 80 Q [l/min] DESCRIPTION APPLICATION
Direct operated 2/2-way solenoid poppet valve in screw-in cartridge Poppet valves are used where tight closing functions of the valve
∆p = f (Q) Pressure loss / flow characteristics
construction for cavity according to Wandfluh standard. In case of are essential like leakfree load holding, clamping or gripping. The
p [bar] the BA execution, the valve is closed in the de-energised position. poppet valve cartridge is mainly used in the mobile and stationary

10 K0159
block construction.

8
6 SYMBOL
4 „Normally closed“ BA
2 2
0
0 10 20 30 40 50 60 70 80 Q [l/min] a b
1

DIMENSIONS
. 2210- . . 2210 TYPE CODE
S D E PM20 - - X5 #
Poppet valve
Direct operated
Solenoid
Screw-in cartridge M20 x 1,5

2/2 way, «normally closed» BA
Without coil (The coil has to be ordered separately)

Design index (subject to change)
1.11-205A
For detailed cavity drawing
and cavity tools see data GENERAL SPECIFICATIONS HYDRAULIC SPECIFICATIONS
E = air bleed screw sheet 2.13-1015 Designation 2/2-way poppet valve Working pressure p = 250 bar
max
Construction Direct operated Maximum volume flow Q = 15 l/min, see characteristics
PARTS LIST max
∗ Cartridge supplied with fastening screw M6 x 90 for steel bodies / Mounting Screw-in cartridge type Leakage volume flow Seat tight, max. 5 drops / min at p
blocs. For aluminium bodies / blocs longer screws are recommended max
Position Article Description (min. 2 screw diameter). Nominal size M20 x 1,5 Fluid Mineral oil, other fluid on request
Actuation Switching solenoid Viscosity range 8 mm /s…420 mm /s
2
2
10 500.4010 Poppet valve cartridge 2210 Ambient temperature -30…+110 °C Temperature range -20…+70 °C
11 052.4202 Spring 1,6 x 13,6 x 26 fluid
12 222.0042 Pin Weight 0,12 kg
13 212.0504 Washer MTTFd 150 years Contamination Class 20 / 18 / 14
14 160.2188 O-ring ID 18,77 x 1,78 efficiency
15 160.2236 O-ring ID 23,52 x 1,78 Filtration Required filtration grade ß 10…16 ≥ 75,
16 160.2230 O-ring ID 23,00 x 1,5 see data sheet 1.0-50
20 260.8… Medium-solenoid SIN60V ACCESSORIES
Cartridge built-in flange- or sandwich body:
260.9… Super-solenoid SIS60V Flange Register 1.11
30 239.2033 Plug Sandwich Register 1.11
(incl. seal) HB0 SURFACE TREATMENT MANUAL OVERRIDE
40 219.2002 Plug Special tool 983.2002 to poppet valve cartridge 2210. ◆ The armature tube and the external parts of the cartridge body None
50 246.3190 Socket head cap screw M6 x 90 DIN 912 Technical explanation see data sheet 1.0-100 are zinc coated

Wandfluh AG Tel. +41 33 672 72 72 E-mail: [email protected] Illustrations not obligatory Data sheet no.
Postfach Fax +41 33 672 72 12 Internet: www.wandfluh.com Data subject to change 1.11.2040E 2/2 www.wandfluh.com Illustrations are not binding Data subject to change 1/2 Edition: 16 38 1.11-205A E
CH-3714 Frutigen Edition 05 02
