2-2-way slip-in cartridge                                                                                                    2-2-way slip-in cartridge
                                                                                       2-way cartridge valves

       GENERAL SPECIFICATIONS                               HYDRAULIC SPECIFICATIONS                                               Control cover                                  NG 40
       Construction       Control cover for check function  Fluid              Mineral oil, other fluid on request                 for check function
       Mounting position   any                              Contamination efficiency  ISO 4406:1999, class 18/16/13                                                               ISO 7368
       Installation dimension   see dimension to ISO 7368                      (Required filtration grade ß6...10≥75)              • p max  = 350 bar
                          see data sheet 2.13-1023                             see data sheet no. 1.0-50/2
       Ambient temperature   -25…+70 °C                     Viskosity range    12 mm /s to 320 mm /s
                                                                                    2
                                                                                              2
       Fastening torque   M = 190 Nm (qual. 8.8) for fixing screws  Fluid temperature   -20…+70 °C
                           D
                                                            Operation pressure   p   = 350 bar
                                                                                max
       DIMENSIONS
                                                                                                                                     Non-return function                 Non-return function in combination with    Non-return function for control via X or Y
                                                                                                                                                                         CS..-10/...-C7                     with integrated shuttle valve
         1             2            3             4            5            6             7            8
          20  10        60
       MD=18 Nm                                               432          A                   B           431
  A                                                                                                           A
          X = G1/4"
          30                         410


           50       30   40
                   MD=190 Nm                                         X=G1/4"                   Y=G1/4"
                                                                    30
  B           5           100                                                                                 B

                                                                                        8.9                                          With integrated shuttle valve (430) and additional pilot valve (431... 434)
           30                        420                                 5           100        5


                                                               433                                         434
                                                                        A                         B
  C                                                                                                           C
                          100





                                                                     X=G1/4"                   Y=G1/4"
  D                                                                                                           D
          X=G1/4"                  Y=G1/4"                           30
          30                            430
                                                                                        8.9
                                                                         5           100        5
             5            100       5
                                                                           01  12.02.2016  BEH     Alle Varianten auf Datenblatt dargestellt  Gezeichnet  04.02.2016  BEH
  E                                                                        02  07.11.2016  BEH     WDMFA06 gedreht - Korrektur  Geprüft  24.11.2016  KL  E
                                                                           03  23.11.2016  BEH     Beschriftung korrigiert  Freigegeben  24.11.2016  TK
                                                                           Rev.  Datum  Name Änderungsnr.  Änderungsbeschrieb  M 1:1  Serie freigegeben
                                                                                                            Gewicht
                                                                           CS-Deckel NG32          Ersetzt durch:   3.872 kg       TYPE CODE
                                                                                                   Ersatz für:
                                                                           D32.../W.               Dok.-Nr.  0192524  Format
                                                                                                            A2
                                                                                     Dokument darf ohne schriftliche Einwilligung weder kopiert,  Art.-Nr.  Revision
                                                                                     verwertet noch an Dritte weitergegeben werden.  DB 1.12-455  03
                                                                                     Zuwiderhandlung ist strafbar und wird gerichtlich verfolgt.
         1             2            3             4            5                              C:\00_Wand uh\Verkauf\Dokumentation\Reg1.12\0192524  Blatt 1 von 1                                         D     40      -                           /        #
                                                                                                                                   Control cover
       PARTS LIST                                           PILOT OPERATED VALVES
                                                                                                                                   Nominal size 40
         Position   Article   Description                                                                                          Pilot no. 410...434
                                                                                                                                   Solenoid type for pilot valve
         10     063.2008    Plate to 410                    Pilot operated valves:  431   WDMFA06-AB1   Data sh. 1.2-59            Standard    431, 432              M  .. / WD
                063.2000    Plate to 420                                    432   WDMFA06-AB2   Data sh. 1.2-59                                433, 434              S
                063.2029    Plate to 430                                    433   AS32060b     Data sh. 1.11-2140                  Nominal voltage U      12 VDC     G12              115 VAC     R115
                063.2032    Plate to 431, 432, 433, 434                     434   AS32061a     Data sh. 1.11-2140                               N         24 VDC     G24              230 VAC     R230
         20     238.2406    Locking screw VSTI G1/4"
                238.3402    Locking screw VSTI G3/8"                                                                               Orifice in cover       0.8 mm     0.8
         30     246.7135    Cyl. screw M16x35 DIN912                                                                                                      1.0 mm     1.0   etc.
         40     221.2470    Pin ∅5x16 DIN1481                                                                                      Omit if without orifice
         50     160.2092    O-Ring ID 9,19x2,62                                                                                    Design-Index (Subject to change)
         60     118.2032    Orifice M5 / 0,8 x 5
                118.2052    Orifice M5 / 0,9 x 5
                118.2031    Orifice M5 / 1,0 x 5
                118.2058    Orifice M5 / 1,2 x 5
                118.2072    Orifice M5 / 1,5 x 5
       Wandfluh AG        Tel.  +41 33 672 72 72   E-mail:  [email protected]   Illustrations not obligatory   Data sheet no.     Wandfluh AG         Tel.  +41 33 672 72 72   E-mail:  [email protected]   Illustrations not obligatory   Data sheet no.
       Postfach           Fax  +41 33 672 72 12   Internet:  www.wandfluh.com   Data subject to change   1.12-455E 2/2             Postfach            Fax  +41 33 672 72 12   Internet:  www.wandfluh.com   Data subject to change   1.12-460E 1/2
       CH-3714 Frutigen                                                                            Edition 20 32                   CH-3714 Frutigen                                                                             Edition 20 32
