Proportional spool valve
                                                                                           Proportional spool valve


            DIMENSIONS
            With analog interface, 12 pole connector             With analog interface, 7 pole connector
            Amplifier and controller                             Amplifier and controller
                  25,30   20,21   40
                                                                               X2
                           X2
                      X1 **   X1 *             MD= 5.2Nm                 X1 **    X1 *

              101.9   X4 ***           9.5    6                    119.9   X4 ***
                                                            69.5
               35                      5.2               38
                                              32                    35


               70    60            50
             MD=5Nm                                                    12.7
                   16.6   14.7    53    57
                                    209                          * For amplifier
                                                                 ** For controller
                    HF1                HS1
                          51                 57                  *** Only controller
                           37                 37
                               80                  90



            With fieldbus interface                              With fieldbus interface
            Amplifier                                            Controller

                              X2                                              X2
                                                                        X1
                         X1
                         X3                                             X3
              101.9
                                                                   119.9   X4

               35

                                                                    35

                      11.8

                                                                      11.8


            PARTS LIST                                           HYDRAULIC CONNECTION

              Position Article  Description
                                                                                      28
                  20 223.1317  Dummy plug M16 x 1,5
                                                                                      14
                  21 160.6131  O-ring ID 13,00 x 1,5 (FKM)
                  25 062.0102  Cover                                                 P
                  30 072.0021  Gasket 33,2 x 59,9 x 2                             A       B
                  40 208.0100  Socket head screw M4 x 10                                          14    27
                                                                                T           T0
                  50 160.2052  O-ring ID 5,28 x 1,78 (NBR)
                     160.6052  O-ring ID 5,28 x 1,78 (FKM)
                  60 160.2187  O-ring ID 18,72 x 2,62 (NBR)
                  70 154.2700  Knurled nut
                  80 253.7004  Push-button
                  90 253.7002  Spindle
