Proportional spool valve
Proportional spool valve

Proportional spool valve with integrated
electronics NG6
ISO 4401-03
Flange construction
◆ direct operated
◆ Q = 40 l/min
max
◆ Q N max = 32 l/min
◆ p = 350 bar
max

DESCRIPTION APPLICATION
Direct operated proportional spool valve with 4 connections in Proportional spool valves are perfectly suitable for demanding
5-chamber system with integrated electronics. The Plug & Play tasks due to the high resolution, large volume flow and low hystere-
valves are factory set and adjusted and have therefore a high sis. The applications are in the industry as well as in the mobile
valve-to-valve reproducibility. With protection class IP67 for the hydraulics for the smooth control of hydraulic actuators. Some
electronics, these valves are suitable for harsh environmental examples: control of the rotor blades of wind generators, forestry
conditions. Proportional to the electronically transmitted and earth moving machines, machine tools and paper production

command value, the spool stroke, the spool opening and the valve machines, simple position controls, robotics and fan control.

volume flow increase. The control takes place via an analogue
interface or a fieldbus interface (CANopen, J1939 or Profibus DP). Note! „PASO” is a Windows programm in the flow diagram
The parameterisation takes place by means of the free of cost para - style, which enables the intuitive adjustment and storing
of all variable parameters. The data remain saved in
meterisation and diagnostics software «PASO» or via fieldbus case of a power failure and can also be reproduced and
interface. The USB parameterisation interface is accessible transferred to other DSV.
through a screw plug. As an option, these valves are available with
integrated controller. As feedback value generators sensors with
voltage or current output can be connected directly. The available
controller structures are optimised for applications with hydraulic
actuations.

SYMBOL
Symmetrical control
ACB-S AC1-S CB2-S
A B A B A B
a 0 b a b
a b a b
P T P T P T

Meter-in control
ADB-V AD1-V DB2-V
A B A B A B
0
a b a b
a b a b
P T P T P T

ELECTRICAL SPECIFICATIONS ACTUATION
Protection class IP67 with suitable mating connector and Actuation Proportional solenoid, wet pin push
closed housing cover type, pressure tight
Ramps Adjustable Connection Via device receptacle
Parameterisation Via fieldbus or USB
Supply voltage 12 VDC, 24 VDC

Note! Exact electrical specifications and detailed description
of «DSV» electronics can be found on data sheet
1.13-76.
