Proportional spool valve
Proportional spool valve Proportional spool valve

TYPE CODE ELECTRICAL CONNECTION
W D P F A06 - - - / M E - # X1 Analog interface (Main) X1 Fieldbus interface (Main)
Spool valve
Device receptacle M23, 12 pole male Device receptacle M12, 4 pole male
Direct operated 1 = Supply voltage + 2 1 1 = Supply voltage +
8 9 1 2 = Supply voltage 0 VDC 3 4 2 = Reserved for extentions
Proportional 7 12 10 2 3 = Stabilised output voltage 3 = Supply voltage 0 VDC
6 11 3
5 4 4 = Command value signal voltage + 4 = Chassis
Flange construction
5 = Command value signal voltage -
International standard interface ISO, NG6 6 = Command value signal current +
7 = Command value signal current -
Designation of symbols acc. to table 8 = Reserved for extentions
9 = Reserved for extentions
Nominal volume flow rate Q N 5 l/min 5 16 l/min 16 10 = Enable signal (Digital input) X2 Parameterisation interface
10 l/min 10 32 l/min 32
11 = Error signal (Digital output) USB, Mini B Under the screw plug of the housing
Nominal voltage U 12 VDC G12 12 = Chassis cover
N
24 VDC G24 Command value signal voltage (PIN 4/5) resp. current (PIN 6/7) are Factory set
selected with parameterisation and diagnostics software PASO.
Slip-on coil Metal housing square

Connection execution Integrated electronics

Hardware configuration
Analog command value signal 12 pole A2 7 pole D2 (-10 … 10 V preset)
Analog command value signal 12 pole A4 7 pole D4 (4 … 20 mA preset) X1 Analog interface (Main) X3 Profibus interface according to
CANopen according to DSP-408 C1 Connector DIN EN 175201 - 804 IEC 947-5-2
Profibus DP according to Fluid Power Technology P1
CAN J1939 (on request) J1 Device receptacle 7 pole male Device receptacle M12, 5 pole female B-coded
A = Supply voltage + 2 3 1 = VP
Function F A B B = Supply voltage 0 VDC 5 2 = RxD / TxD - N
Amplifier G C = Not connected 1 4 3 = DGND
Controller with current feedback value signal (0 … 20 mA / 4 … 20 mA) R1 E C D = Command value signal + 4 = RxD / TxD - P
Controller with voltage feedback value signal (0 … 10 V) R2 D
E = Command value signal - 5 = Shield
Sealing material NBR F = Not connected
FKM (Viton) D1 G = Chassis
Command value signal: current (D4) or voltage (D2) to specify
Manual override integrated
Push-button HF1 when placing the order
Spindle HS1
Design index (subject to change)
1.10-3340
X3 CANopen interface according to DRP X4 (controller only) Feedback value interface (sensor)
GENERAL SPECIFICATIONS HYDRAULIC SPECIFICATIONS 303-1 Device receptacle M12, 5 pole female
Device receptacle M12, 5 pole male 1 = Supply voltage (output) +
Designation Proportional spool valve Working pressure p = 350 bar 1 = Not connected 2 3 2 = Feedback value signal +
5
max
Construction Direct operated Tank pressure p = 160 bar 2 1 1 4
T max 5 2 = Not connected 3 = Supply voltage 0 VDC
Mounting Flange construction Maximum volume flow Q = 40 l/min, see characteristics 3 4
max 3 = CAN Gnd 4 = Not connected
Nominal size NG6 according to ISO 4401-03 Nominal volume flow Q = 5, 10, 16, 32 l/min 4 = CAN High 5 = Stabilised output voltage
N
Actuation Proportional solenoid Leakage oil On request 5 = CAN Low Feedback value signal: current (R1) or voltage (R2) to specify
Ambient temperature -20…+65 °C Hysteresis ≤ 6 % when placing the order
The upper temperature limit is a Fluid Mineral oil, other fluid on request
guideline for typical applications, in Viscosity range 12 mm /s…320 mm /s
2
2
individual cases it may also be higher or Temperature range -25…+70 °C (NBR) Note! The mating connector is not included in the delivery
lower. The electronics of the valve limit fluid -20…+70 °C (FKM)
the power in case of a too high Contamination Class 18 / 16 / 13
electronics temperature. More detailed efficiency
information can be obtained from the
operating instructions „DSV”. Filtration Required filtration grade ß 10…16 ≥ 75,
Weight 2,8 kg see data sheet 1.0-50
MTTFd 150 years

www.wandfluh.com Illustrations are not binding Data subject to change 2/6 Edition: 19 29 1.10-3340 E www.wandfluh.com Illustrations are not binding Data subject to change 3/6 Edition: 19 29 1.10-3340 E
