Poppet valve
Poppet valve Poppet valve

GENERAL SPECIFICATIONS ACTUATION VALVES INSTALLED
Designation 2/2-, 3/2- and 3/4-way poppet valve Actuation Switching solenoid, wet pin push type, The central functioning element is the poppet valve cartridge listed below
Construction Direct operated pressure tight Article Description Data sheet no.
Mounting Flange construction Execution Medium: SIN45V (Data sheet 1.1-120) 2206 Solenoid poppet valve cartridge normally closed NG6 1.11-2030
Nominal size NG6 according to ISO 4401-03 Super: SIS45V (Data sheet 1.1-125) DIMENSIONS
Actuation Switching solenoid Connection Connector socket EN 175301 – 803 3/2-; 2/2-way 3/2-; 2/2-way
Ambient temperature -25…+70 °C 30 35
Weight 1,8 kg (2/2- and 3/2-way) COMMISSIONING
2,8 kg (3/4-way) Attention! When commissioning, the valve must be vented under A 9.5 B
MTTFd 150 years pressure (max. two rotations of screw E). 5.5 MD= 5.2Nm
8
85
E
45 45 46
38

ELECTRICAL SPECIFICATIONS HYDRAULIC SPECIFICATIONS
50
Protection class IP65 Working pressure Medium: p = 160 bar 20 MD=5.2Nm 10 70 40 60 10
max
Relative duty factor 100 % DF Super: p = 350 bar MD= 9.5Nm 4 64 64 15 MD= 5.2Nm 64
max
Switching frequency 15'000 / h Maximum volume flow Q = 40 l/min, see characteristic 138 A.22061a 153 A.22060b
153 A.32060b
max
Service life time 10 (number of switching cycles, Volume flow direction Any (see characteristic) E = Air bleed screw 153 A.32061a
7
theoretically) Leakage oil Poppet type, max. 0,05 ml / min (approx. 3/4-way
Voltage tolerance ± 10 % with regard to nominal voltage 1 drop / min) at 30 cSt
Standard nominal 12 VDC, 24VDC, 115 VAC, 230 VAC Fluid Mineral oil, other fluid on request 30 35
voltage AC = 50 to 60 Hz, rectifier integrated in Viscosity range 12 mm /s…320 mm /s A B
2
2
the connector socket Temperature range -25…+70 °C (NBR)
fluid -20…+70 °C (FKM)
Note! Other electrical specifications see data sheet 1.1-120
(Medium) and 1.1-125 (Super) Contamination Class 20 / 18 / 14
efficiency
Filtration Required filtration grade ß 10…16 ≥ 75,
see data sheet 1.0-50 10 90
PERFORMANCE SPECIFICATIONS 238
Oil viscosity u = 30 mm /s HYDRAULIC CONNECTION PARTS LIST
2
∆p = f (Q) Pressure drop volume flow characteristic p = f (Q) Performance limits „Medium” Position Article Description
Measured with nominal voltage -10%
p [bar] 17.8 10 260.6... Solenoid SIN45V
35 K0078 p [bar] T 260.7... Solenoid SIS45V
30 200 K0077
25 31 A B 21 20 239.2033 Screw plug HB0 (incl. seal)
20 150 32.5 30 219.2001 Electric plug A (grey)
15
10 100 P 35 219.2002 Electric plug B (black)
5 50 21.5 40 058.4215 Cover
0 40.5
0 5 10 15 20 25 30 35 40 Q [l/min] 0 50 246.2160 Socket head screw M5 x 60 DIN 912
0 5 10 15 20 25 30 35 40 Q [l/min] 60 246.2117 Socket head screw M5 x 16 DIN 912
70 160.2093 O-ring ID 9,25 x 1,78 (NBR)
160.6092 O-ring ID 9,25 x 1,78 (FKM)
p = f (Q) Performance limits „Super” Flow direction
Measured with nominal voltage -10% Type P - A A - T A - P T - A
p [bar] AS22061a 1 - 2 -
350 K0127 1 AS22060b 1 - 4 - SEALING MATERIAL STANDARDS
300 2 NBR or FKM (Viton) as standard, choice in the type code
250 3 4 AS32061a 1 2 3 1 Mounting interface ISO 4401-03
200 AS32060b 1 2 3 1 Solenoids DIN VDE 0580
150 Connection execution D EN 175301 – 803
100 AS3406 1 1 2 2
500 Protection class EN 60 529
0 Attention! Long periods of non-actuation can reduce the switching Contamination efficiency ISO 4406
0 5 10 15 20 25 30 35 40 Q [l/min] performance
