Poppet valve
Poppet valve Solenoid operated poppet valve

SEALING MATERIAL STANDARDS Solenoid operated poppet valve with additional
NBR or FKM (Viton) as standard, choice in the type code Mounting interface ISO 4401-05 inductive switching position monitoring NG10

Solenoids DIN VDE 0580 Flange construction ISO 4401-05
Connection execution D EN 175301 – 803 ◆ 2/2- and 3/2-way
Protection class EN 60 529 ◆ normally open and normally closed
Contamination efficiency ISO 4406 ◆ Q = 80 l/min
max
◆ p = 350 bar
max

ACCESSORIES MANUAL OVERRIDE
Fixing screws Data sheet 1.0-60 Screw plug (HB0), no actuation possible DESCRIPTION
Optionally: HB8,5, HN(K) or HG(K) Solenoid operated poppet valve according to data sheet 1.11-2160
Threaded subplates Data sheet 2.9-05 → See data sheet 1.1-311 with additional inductive switching position monitoring. The con-
Multi-station subplates Data sheet 2.9-45 tactless sensor transmits the poppet position to a step signal.

Horizontal mounting blocks Data sheet 2.9-85
Technical explanations Data sheet 1.0-100 TYPE CODE
Filtration Data sheet 1.0-50
Relative duty factor Data sheet 1.1-430 2/2 or 3/2 way execution A 2 10 - - #
International standard interface ISO
Solenoid, Medium M
Solenoid, Super S
INSTALLATION NOTES SURFACE TREATMENT
Mounting type Flange mounting ◆ The valve body is painted with a two component paint 2 way (connections) 2 3
3 way (connections)
4 fixing holes for ◆ The solenoid and the cover are re zinc-nickel coated
socket head screws M5 x 65 ◆ The socket head screws are zinc coated 2 switching positions
Mounting position Any, preferably horizontal
Tightening torque Fixing screws M = 8,9 Nm (quality 8.8, Nominal size 10
D
zinc coated) Normally closed Solenoid on A-side 1a
Normally open Solenoid on B-side 0b
Note! The length of the fixing screw depends on the base
material of the connection element. Other type designation according to type code data sheet 1.11-2160

Polarity /Signal output /Monitoring
PNP / NO / Single Z603
PNP / NC / Single Z482
NPN / NO / Single Z680
Design index (subject to change)
1.11-2162
GENERAL SPECIFICATIONS ACCESSORIES
Weight 5,30 kg (22101) Mating connector (plug female)
5,95kg (22100; 3210.) straight, screw terminal Article no. 219.2978
Sensor Specifications: 90°, screw terminal Article no. 219.3003

Nominal voltage 24 VDC
Operating voltage 10…30 VDC SURFACE TREATMENT
Signal current max. 200 mA ◆ The valve body is painted with a two component paint
Switching frequency 2000 Hz ◆ The solenoid, the flange and the cover are zinc coated
Protection class IP 68 ◆ The socket head screws are zinc coated
According to the connection type,
the protection class of the valve can be
lower, see data sheet 1.11-2160
Dimensions M12 x 1
Ambient temperature -25…50 °C Note! Other specifications see data sheet 1.11-2160
Fastening torque 15 Nm
Wandfluh AG Postfach CH-3714 Frutigen Peak pressure 500 bar
Tel. +41 33 672 72 72 Fax +41 33 672 72 12 [email protected]

www.wandfluh.com Illustrations are not binding Data subject to change 4/4 Edition: 21 16 1.11-2160 E www.wandfluh.com Illustrations are not binding Data subject to change 1/2 Edition: 17 20 1.11-2162 E
