G.2210
Poppet valve G.2210

GENERAL SPECIFICATIONS HYDRAULIC SPECIFICATIONS VALVES INSTALLED
Designation 2/2-way poppet valve Working pressure Medium: p = 160 bar The central functioning element is the poppet valve cartridge NG10, data sheet 1.11-2040.
max
Construction Direct operated Super: p = 350 bar
max
Mounting Installation in pipes Maximum volume flow Q = 80 l/min, see characteristic DIMENSIONS
max
Nominal size NG10 Volume flow direction Any (see characteristic) G.22101 G.22100
Connection Threaded connection G1/2“ Leakage oil Seat tight, max. 0,05 ml / min (approx. 1 157 70 18 93 198
Actuation Switching solenoid drop / min) at 30 cSt 30 A 50 50 B 35
Ambient temperature -25…+70 °C (NBR) Fluid Mineral oil, other fluid on request 28 28
2
2
-20…+70 °C (FKM) Viscosity range 12 mm /s…320 mm /s
Weight ≤ 4,0 kg Temperature range -20…+70 °C 101 E E 105
MTTFd 150 years fluid 60 62 70 60 60

Contamination Class 20 / 18 / 14
efficiency
ELECTRICAL SPECIFICATIONS Filtration Required filtration grade ß 10…16 ≥ 75, G1/2" 70 60 40 G1/2" 10 50 20
Protection class IP65 see data sheet 1.0-50 MD=8.9Nm MD= 8.9Nm MD=9.5Nm
Relative duty factor 100 % DF
Switching frequency 15'000 / h PARTS LIST MANUAL OVERRIDE
Service life time 10 (number of switching cycles, STANDARDS Position Article Description Screw plug (HB0), no actuation possible
7
theoretically) Optionally: HB8,5; HN(K) or HR(K)
Voltage tolerance ± 10 % with regard to nominal voltage Solenoids DIN VDE 0580 10 260.8... Solenoid SIN60V → See data sheet 1.1-311
Solenoid SIS60V
260.9...
Standard nominal 12 VDC, 24VDC, 115 VAC, 230 VAC Connection execution D EN 175301 – 803
voltage AC = 50 to 60 Hz, rectifier integrated in Protection class EN 60 529 20 239.2033 Screw plug HB0 (incl. seal) INSTALLATION NOTES
the connector socket Contamination efficiency ISO 4406 30 219.2001 Electric plug A (grey)
35 219.2002 Electric plug B (black) Mounting position Any, preferably horizontal
Note! Other electrical specifications see data sheet 1.1-145
(Medium) and 1.1-150 (Super) 40 059.2200 Cover
50 246.3190 Socket head screw M6 x 90 DIN 912 ACCESSORIES
60 246.3121 Socket head screw M6 x 20 DIN 912 Technical explanations Data sheet 1.0-100
Hydraulic fluids Data sheet 1.0-50
SEALING MATERIAL SURFACE TREATMENT
NBR or FKM (Viton) as standard, choice in the type code ◆ The valve body, the solenoid, the cover and the socket head Filtration Data sheet 1.0-50
srews are zinc coated Relative duty factor Data sheet 1.1-430

PERFORMANCE SPECIFICATIONS
Oil viscosity u = 30 mm /s
2
p = f (Q) Performance limits Δp = f (Q) Pressure drop volume-flow characteristics
Measured with nominal voltage -10 % p [bar]
p [bar] 10 K0159
350 K0158 1 8
300
250 2 6
200 4
150 2
100 3
50 4 0 0 10 20 30 40 50 60 70 80 Q [l/min]
0
0 10 20 30 40 50 60 70 80 Q [l/min]

Flow direction
Type P → A A → P
GM2210. 3 4
GS2210. 1 2
Wandfluh AG Postfach CH-3714 Frutigen
Tel. +41 33 672 72 72 Fax +41 33 672 72 12 [email protected]

www.wandfluh.com Illustrations are not binding Data subject to change 2/3 Edition: 17 22 1.11-2860 E www.wandfluh.com Illustrations are not binding Data subject to change 3/3 Edition: 17 22 1.11-2860 E
