P. 598

G.2206
                                                                                                Poppet valve                                                                                                                       G.2206


       GENERAL SPECIFICATIONS                              HYDRAULIC SPECIFICATIONS                                                VALVES INSTALLED
       Designation        2/2-way poppet valve              Working pressure   Medium: p  = 160 bar                                The central functioning element is the poppet valve cartridge NG6, data sheet 1.11-2030.
                                                                                      max
       Construction       Direct operated                                      Super: p  = 350 bar
                                                                                     max
       Mounting           Installation in pipes             Maximum volume flow  Q  = 40 l/min, see characteristic                 DIMENSIONS
                                                                                max
       Nominal size       NG6                               Volume flow direction  Any (see characteristic)                        G.22061                                              G.22060
       Connection         Threaded connection G3/8“         Leakage oil        Seat tight, max. 0,05 ml / min (approx. 1                              124                                                      153
       Actuation          Switching solenoid                                   drop / min) at 30 cSt                                                        33.5   50                            15    33.5    64
       Ambient temperature  -25…+70 °C (NBR)                Fluid              Mineral oil, other fluid on request                    30        A         16.5                                      16.5                B        35
                                                                                            2
                                                                                   2
                          -20…+70 °C (FKM)                  Viscosity range    12 mm /s…320 mm /s
       Weight             ≤ 1,7 kg                          Temperature range   -20…+70 °C
       MTTFd              150 years                         fluid                                                                     87   E                                                                                     E     87
                                                            Contamination      Class 20 / 18 / 14                                      45                                                 50   45                                   45
                                                            efficiency
       ELECTRICAL SPECIFICATIONS                            Filtration         Required filtration grade ß 10…16 ≥ 75,
       Protection class   IP65                                                 see data sheet 1.0-50                                                           G3/8"          50            60  40       G3/8"         10    50   20
       Relative duty factor  100 % DF                                                                                              E = Air bleed screw                                  MD=5.2Nm                          MD=5.2Nm  MD=9.5Nm
       Switching frequency  15'000 / h
       Service life time  10  (number of switching cycles,
                            7
                          theoretically)                   STANDARDS
       Voltage tolerance  ± 10 % with regard to nominal voltage  Solenoids       DIN VDE 0580                                      PARTS LIST                                           MANUAL OVERRIDE
       Standard nominal   12 VDC, 24VDC, 115 VAC, 230 VAC   Connection execution D  EN 175301 – 803                                  Position Article  Description                      Screw plug (HB0), no actuation possible
       voltage            AC = 50 to 60 Hz, rectifier integrated in   Protection class  EN 60 529                                        10 260.6...  Solenoid SIN45V                   Optionally: HB6; HN(K) or HR(K)
                          the connector socket              Contamination efficiency  ISO 4406                                              260.7...  Solenoid SIS45V                   → See data sheet 1.1-311
       Note!   Other electrical specifications see data sheet 1.1-120                                                                    20 239.2033  Screw plug HB0 (incl. seal)       INSTALLATION NOTES
               (Medium) and 1.1-125 (Super)                                                                                              30 219.2001  Electric plug A (grey)
                                                                                                                                                                                         Mounting position  Any, preferably horizontal
                                                                                                                                         35 219.2002  Electric plug B (black)
                                                                                                                                         40 058.4215  Cover
       SEALING MATERIAL                                    SURFACE TREATMENT                                                             50 246.2160  Socket head screw M5 x 60 DIN 912  ACCESSORIES
       NBR or FKM (Viton) as standard, choice in the type code  ◆  The valve body, the solenoid, the cover and the socket head                                                           Technical explanations      Data sheet 1.0-100
                                                              srews are zinc coated                                                      80 246.2117  Socket head screw M5 x 16 DIN 912
                                                                                                                                                                                         Hydraulic fluids            Data sheet 1.0-50
                                                                                                                                                                                         Filtration                  Data sheet 1.0-50
                                                                                                                                                                                         Relative duty factor        Data sheet 1.1-430
       PERFORMANCE SPECIFICATIONS
       Oil viscosity u = 30 mm /s
                       2
       p = f (Q)  Performance limits                        Δp = f (Q)  Pressure drop volume flow characteristics
                  Measured with nominal voltage -10 %
                                                               p [bar]
           p [bar]                              1             30  K0129
         350  K0128                                           25
         300                                    2             20
         250                                                  15
         200                                    3             10
         150
         100                                                   5
          50                                                   0
           0                                                    0    5  10   15  20  25   30  35  40  Q [l/min]
            0   5   10  15   20  25  30  35   40  Q [l/min]



                                    Flow direction
                Type            P → A          A → P
              GM2206.             3             3
              GS2206.             1             2

                                                                                                                                                                                        Wandfluh AG  Postfach  CH-3714 Frutigen
                                                                                                                                                                                        Tel. +41 33 672 72 72  Fax +41 33 672 72 12  [email protected]

                       www.wandfluh.com  Illustrations are not binding  Data subject to change  2/3  Edition: 17 22  1.11-2840 E                   www.wandfluh.com  Illustrations are not binding  Data subject to change  3/3  Edition: 17 22  1.11-2840 E
