Page 482 - Softbound_Edition_19_en

Poppet valve
Poppet valve cartridge Poppet valve

CERTIFICATES ACTUATION PERFORMANCE SPECIFICATIONS
2
Surface Mining Actuation Switching solenoid, wet pin push type, Oil viscosity u = 30 mm /s
gas and dust pressure tight p = f (Q) Performance limits Flow direction
ATEX / UKEX x x Execution M.Z45 (Data sheet 1.1-185) rotatable in Measured with nominal voltage -10 % Execution 1 → 2 2 → 1 2 → 3 3 → 2
IECEx x x steps of 90 ° and easy exchangeable Measured at 50 °C SDZPM18-AB 1 1 - -
Connection Through cable gland for cable Ø 6…12 mm P ≥ 0,81 W (90 mA, 100 Ohm)
CCC x x SDZPM18-BA 1 1 - -
two phase conductors +/- as well as one p [bar]
The certificates can be found on www.wandfluh.com ground conductor 250 K4142 4 2 1 SDZPM18-FG 2 3 3 4
200
150
100 3
50
0
GENERAL SPECIFICATIONS HYDRAULIC SPECIFICATIONS 0 2 4 6 8 Q [l/min]

Designation 2/2-, 3/2-poppet valve Working pressure p = 250 bar
max
Construction Direct operated Maximum volume flow Q = 8 l/min, see characteristics
max p = f (Q) Performance limits Flow direction
Mounting Screw-in cartridge construction Leakage oil Seat tight
Nominal size M18 x 1,5 according to ISO 7789 Fluid Mineral oil, other fluid on request Measured with nominal voltage -10 % Execution 1 → 2 2 → 1 2 → 3 3 → 2
Measured at 50 °C
Actuation Ex-protection switching solenoid Viscosity range 12 mm /s…320 mm /s P ≥ 0,62 W (64 mA, 152 Ohm) SDZPM18-AB 1 1 - -
2
2
Ambient temperature -20…+45 °C (operation as T6) Temperature range -20…+45 °C (operation as T6) SDZPM18-BA 1 1 - -
-20…+60 °C (operation as T1…T5) fluid -20…+60 °C (operation as T1…T5) 250 p [bar] 3 4 2 SDZPM18-FG 2 1 3 4
K4143
Weight 2,32 kg Contamination Class 20 / 18 / 14 1
MTTFd 150 years efficiency 200
Filtration Required filtration grade ß 10…16 ≥ 75, 150
see data sheet 1.0-50 100
50
0
0 1 2 3 4 5 6 Q [l/min]

∆p = f (Q) Pressure drop volume flow characteristics Flow direction
ELECTRICAL SPECIFICATIONS ACCESSORIES
p [bar] Execution 1 → 2 2 → 1 2 → 3 3 → 2
Protection class IP65 Technical explanations Data sheet 1.0-100 10 K4144 SDZPM18-AB 2 1 - -
Relative duty factor Continuous operation Hydraulic fluids Data sheet 1.0-50 8 SDZPM18-BA 1 1 - -
Switching frequency 1'800 / h Filtration Data sheet 1.0-50 6 3
Service life time 10 (number of switching cycles, Relative duty factor Data sheet 1.1-430 4 SDZPM18-FG 2 2 3 3
7
theoretically)
Voltage tolerance ± 10 % with regard to nominal voltage 2 2 1
Limiting current at I = 90 mA (100 Ω execution) 0 0 2 4 6 8 Q [l/min]
min
50 °C I = 64 mA (152 Ω execution)
min
Temperature class T1…T6
Coil resistance 100 Ω, 152 Ω
Minimum power P = 0,81 W (100 Ω execution)
min
consumption P = 0,62 W (152 Ω execution)
min STANDARDS INSTALLATION NOTES
Note! Other electrical specifications see data sheet 1.1-185 Cartridge cavity ISO 7789 Mounting type Screw-in cartridge M18 x 1,5
Explosion protection Directive 2014 / 34 / EU (ATEX) Mounting position Any, preferably horizontal
Flameproof enclosure EN / IEC 60079-1 / 31 Tightening torque M = 40 Nm Screw-in cartridge
D
Cable entry EN 60079-0, 1, 7, 15, 31 M = 5 Nm knurled nut
D
Protection class EN 60 529
Contamination ISO 4406
efficiency

www.wandfluh.com Illustrations are not binding Data subject to change 2/4 Edition: 22 15 1.11-2054 E www.wandfluh.com Illustrations are not binding Data subject to change 3/4 Edition: 22 15 1.11-2054 E
